The CT1698 is a Manchester encoder/decoder from Aeroflex, designed for use in various digital communication systems.
📖 Datasheet Preview
⬇️ Download Complete Datasheet
Get the full 7-page technical datasheet in PDF format
📝 Component Overview
The CT1698 is a Manchester encoder/decoder from Aeroflex, designed for use in various digital communication systems. It operates with a clock frequency of up to 10MHz and is capable of encoding and decoding data according to the Manchester protocol. The device is suitable for applications requiring data transmission and reception in accordance with this specific protocol.
Key Features and Benefits
- Manchester Encoder/Decoder
- Up to 10MHz Clock Frequency
- Data Encoding and Decoding
- Suitable for Digital Communication Systems
- Compliant with Manchester Protocol
- Available in Various Packages
Typical Applications
- Digital Communication Systems
- Data Transmission and Reception
- Manchester Protocol-Based Systems
- Encoder and Decoder Applications
- High-Speed Data Transfer
- Telecommunication Equipment
📊 Complete Technical Specifications
Absolute Maximum Ratings
| Parameter | Value |
|---|---|
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -65°C to +150°C |
Electrical Characteristics
| Parameter | Condition | Min | Typ | Max | Unit |
|---|---|---|---|---|---|
| Clock Frequency | Maximum | N/A | 10MHz | 10MHz | MHz |
| Supply Voltage | Recommended | 4.5V | 5V | 5.5V | V |
Package Information
- DIP (Dual In-Line Package): Through-hole package with 16 pins
- SOIC (Small Outline Integrated Circuit): Surface-mount package with 16 pins
Pin Configuration
- Pin 1: VCC - Positive Supply Voltage
- Pin 2: GND - Ground
🔧 Application Guidelines
Design Considerations
When designing with the CT1698, consider the clock frequency, data rate, and power consumption. Ensure the device is properly powered and that the clock signal is stable and within the specified frequency range.
Installation Guidelines
Mount the CT1698 on a suitable PCB, ensuring all pins are securely connected. Use appropriate soldering techniques to prevent damage to the device.
Operational Notes
The CT1698 operates with a Manchester encoding scheme. Ensure that the system design accounts for this protocol to achieve proper data transmission and reception.
